En1175-2020 100A 24v Brushed Dc Motor Speed Controller Intended For The Traction Control Of Lightweight CLASS III Stac

Product Details

Place of Origin: Chengdu,China

Brand Name: DALA

Model Number: D2E

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: standard packing, as customer demands

Delivery Time: 7 - 15 working Days

Payment Terms: L/C,T/T,etc.

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                    En1175-2020 Brushed Dc Controller, En1175 Brushed Dc Controller, 100A 24v Brushed Motor Controller


Motor Type:	DC Brushed Motor	Function:	Traction
Application:	Forklift Electric Forklifts,Floor-Cleaning Vehicles,And More	Nominal Voltage Range (VDC):	24V
Maximum Current:	100A	Size:	135.575.546.5mm

Motor Type:	DC Brushed Motor
Function:	Traction
Application:	Forklift Electric Forklifts,Floor-Cleaning Vehicles,And More
Nominal Voltage Range (VDC):	24V
Maximum Current:	100A
Size:	135.575.546.5mm

Description

En1175-2020 100A 24v Brushed Dc Motor Speed Controller Intended For The Traction Control Of Lightweight CLASS III Stac

Brushed Speed Controller D2E 24V 100A Certification en1175-2020 Functional integrity

Product Description:

The D2E controller is a brushed DC motor controller intended for the traction control of lightweight CLASS III stacker or truck. It’s also applicable to many other industrial vehicles of similar requirements.

D2E is fully programmable and highly parameterized for easy application and maintenance for customer.

Features:

Functional integrity

Rating voltage/current 24V/100A
Two, microprocessor units, cross check & high diagnostic coverage
Powerful relay rating 24V/70A imbedded.
M5 Bolt-on connection for bus-bar
Certification passed: EN13849-1(Cat2, PL=D)
CAN & UART port supported.
IP65 sealing standard adopted.

Safety and Reliability

Monitoring system for traction control
Interlock Braking
Emergency Reverse
Safety Brake
Speed Limit Monitoring
Hazardous Load Handling Monitoring

Specifications

Content	Parameters
Model	D2E
Certification	EN1175-2020
Nominal Input Voltage	24
20s output Current Rating (A)	100A
2 Min output Current Rating (A)	60A
60 Min output Current Rating (A)	40A
Communication	Serial / CAN
Operating Temperature	-30℃~55℃
Storage Temperature	-40℃~85℃
IP Rating	IP65
Motor Type	Brushed DC Motor (Bi-Di)

Applications

En1175-2020 100A 24v Brushed Dc Motor Speed Controller Intended For The Traction Control Of Lightweight CLASS III Stac 0

Dimensions

En1175-2020 100A 24v Brushed Dc Motor Speed Controller Intended For The Traction Control Of Lightweight CLASS III Stac 1
