24V stepper motor controller for Scrubber-Dryer Traction,Vaccum

Name: 24V stepper motor controller for Scrubber-Dryer Traction,Vaccum
Brand: Dala Technology Co., Ltd.
SKU: XD240
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: DALA

Model Number: XD240

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: standard packing, as customer demands

Delivery Time: 7 - 15 working Days

Payment Terms: L/C,T/T,etc.

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            Vacuum Traction DC Speed Controller 24V, Traction DC Speed Controller 24V 45A, 45A 24 Volt Motor Speed Controller


Motor Type:	DC Brushed Motor	Appolication:	Ride-on Scrubber-Dryer
Function:	Traction,Vaccum	Nominal Voltage Range (VDC):	24V
Maximum Current:	45	Communication:	Serial
SIZE:	1317238.2

Motor Type:	DC Brushed Motor
Appolication:	Ride-on Scrubber-Dryer
Function:	Traction,Vaccum
Nominal Voltage Range (VDC):	24V
Maximum Current:	45
Communication:	Serial
SIZE:	1317238.2

Description

24V stepper motor controller for Scrubber-Dryer Traction,Vaccum

DC motor driver XD240 24V 45A Control 2 motors simultaneously Vaccum Traction

Product Description:

XD240 24V DC motor controller is designed for light-duty walk-behind or ride-on scrubber-dryer's brush & vacuum control. It’s a mature and mainstream product of DALA for cleaning machine industry which has been proved to be a powerful and stable controller product with many use cases.

Features:

Perfect Functionality

Reliable and high quality standard MOSFET adopted as a key component of reliability.
Utilized comprehensive fault prevention technologies and safety protection measures combined industrial practice and innovations.
Solenoid valve short-circuit protection and open circuit protection.

Safe and Reliable

Reliable MOSFET.
Electronics sealed and heat transfer design.
Faulty detection, comprehensively over-voltage, under-voltage, over-current, over-temperature protection.
Solenoid valve short protection and open protection.

Simple & Flexible

Simplified wiring.
Software program upgrade can be done remotely with PC programmer tool.

Specifications :

Content	Parameters
Model	XD240
Rated Voltage (V)	24
Communication	Serial
Motors	Traction	Vaccum
30s RMS Current Rating (A)	45A	30A
60 Min RMS Current Rating (A)	30A	20A
Ingress Protection Rating	IP65
Working Temperater	-30℃~55℃
Ambient Temperater	-40℃~85℃

Appolication:

24V stepper motor controller for Scrubber-Dryer Traction,Vaccum 0

Dimensions:

24V stepper motor controller for Scrubber-Dryer Traction,Vaccum 1
